Starter
0 986 018 040
Catalog number:
Manufacturer:
BOSCH
Exchange Part
Voltage [V] : 12
Rated Power [kW] : 1,1
Number of mounting bores : 2
Number of threaded holes : 0
Number of Teeth : 10
Clamp : 50
Clamp : 30
Flange Diameter [mm] : 76,2
Rotation Direction : Anticlockwise rotation
Pinion Rest Position [mm] : 52,5
Starter Type : Floating pinion
Bore Diameter [mm] : 12,5
Bore Diameter 2 [mm] : 12,5
Length [mm] : 211
Position/Degree : links
Mounting Angle [degrees] : 42
Mounting bore angle measurement [degree] : 42
