Piston
87-501800-10
Catalog number:
Manufacturer:
NÜRAL
Production Number : 08245-103
Recess Depth 1 [mm] : 4,25
Piston Clearance [mm] : 0,035
Piston Protrusion [mm] : 0,7
Compression Height [mm] : 30,8
Height [mm] : 52,5
Cylinder Bore [mm] : 82,5
Bolt Head Diameter [mm] : 21
Recess Diameter [mm] : 61
Bolt Length [mm] : 55
Component Number : 08-501800-00
Standard Size [STD]
