Piston
028 21 00
Catalog number:
Manufacturer:
MAHLE
Cylinder Bore [mm] : 81,0
Length [mm] : 69,8
Compression Height [mm] : 45,75
Bolt Length [mm] : 66,0
Bolt Head Diameter [mm] : 26,0
Recess Depth 1 [mm] : 17,6
Recess Diameter [mm] : 37,9
Valve Pocket Depth 1 [mm] : 0,8
Machined : with cut-out for oil jet
Surface : Coated
Supplementary Article/Supplementary Info 2 : with piston ring carrier
Supplementary Article/Supplementary Info 2 : with cooling duct
Top Land Height [mm] : 9,5
Fitting Position : for cylinder 3
Fitting Position : for cylinder 4
Fitting Position : for cylinder 5
Connecting Rod Design : Trapezoidal Connecting Rod
Production Number : 81 L 103
Piston Clearance [mm] : 0,05
Component Number : 1. R2.5 IW CrK
Component Number : 2. M 2.0 IFU P
Component Number : 3. DSF 3.0 Cr
Packaging height [cm] : 12,80
Net Weight [g] : 811
Packaging length [cm] : 9,5
Packaging width [cm] : 9,50
