Piston
028 16 00
Catalog number:
Manufacturer:
MAHLE
Cylinder Bore [mm] : 83,01
Length [mm] : 70,8
Compression Height [mm] : 46,3
Bolt Length [mm] : 68
Bolt Head Diameter [mm] : 30
Recess Depth 1 [mm] : 15,1
Recess Diameter [mm] : 45
Machined : with cut-out for oil jet
Surface : Coated
Supplementary Article/Supplementary Info 2 : with piston ring carrier
Supplementary Article/Supplementary Info 2 : with cooling duct
Top Land Height [mm] : 10
Production Number : 83 L 57
Piston Clearance [mm] : 0,06
Component Number : 1. R 2.0 CrK
Component Number : 2. M2.0 IFU Mo
Component Number : 3. DSF 3.0 Cr
Packaging height [cm] : 12,80
Net Weight [g] : 554
Packaging length [cm] : 9,5
Packaging width [cm] : 9,50
