Piston
022 06 00
Catalog number:
Manufacturer:
MAHLE
Standard Size [STD]
Cylinder Bore [mm] : 79,5
Length [mm] : 54,7
Compression Height [mm] : 31,7
Bolt Length [mm] : 62,0
Bolt Head Diameter [mm] : 20,0
Recess Depth 1 [mm] : 1,3
Recess Diameter [mm] : 69
Valve Pocket Depth 1 [mm] : 1,9
Surface : Tin-plated
Supplementary Article/Supplementary Info 2 : without cooling duct
Top Land Height [mm] : 6
Production Number : 79 L 97
Piston Clearance [mm] : 0,03
Component Number : 1. R 1.5 Mo
Component Number : 2. NM 1.5
Component Number : 3. 3S 2.5 Cr
Packaging height [cm] : 12,80
Net Weight [g] : 419
Packaging length [cm] : 9,5
Packaging width [cm] : 9,50
