Brake Drum
JAP560914C
Catalog number:
Manufacturer:
Japko
Inner brake drum diameter [mm] : 268,1
Inner brake drum height [mm] : 68,5
Outer brake drum diameter [mm] : 311
Total brake drum height [mm] : 88
Hole Arrangement/Number : 05/09
Bolt Hole Circle [mm] : 112
Centering Diameter [mm] : 68,1
max. brake drum reboring dimension [mm] : 269,5
Wheel Bolt Bore Diameter [mm] : 16,8
Number of Holes : 5
Surface : painted
