Brake Drum
ASH56-00-0409C
Catalog number:
Manufacturer:
Ashika
Inner brake drum diameter [mm] : 203,3
Inner brake drum height [mm] : 50,5
Outer brake drum diameter [mm] : 234
Total brake drum height [mm] : 76
Bolt Hole Circle [mm] : 100
max. brake drum reboring dimension [mm] : 204,5
Number of Holes : 4
Centering Diameter [mm] : 52
Surface : painted
