Brake Disc
78BD9115-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 10
Outer diameter [mm] : 278
Brake Disc Type : solid
Height [mm] : 41,6
Centering Diameter [mm] : 65,5
Bolt Hole Circle [mm] : 110
Axle Version : Rear
Technical Information Number : 78BD9115-2
Test Mark : E1 90R-02C0100/0677
Test Mark : E1 90R-02C0415/0088
Diameter [mm] : 65,5
Thickness [mm] : 12
Minimum thickness [mm] : 10
Hole Arrangement/Number : 5
Weight [kg] : 9644,000
