Brake Disc
78BD9005-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 26
Outer diameter [mm] : 313,5
Brake Disc Type : Vented
Height [mm] : 44,8
Centering Diameter [mm] : 70
Bolt Hole Circle [mm] : 110
Axle Version : Front
Technical Information Number : 78BD9005-2
Test Mark : E1 90R-02C0433/0096
Diameter [mm] : 70
Thickness [mm] : 28
Minimum thickness [mm] : 26
Hole Arrangement/Number : 5
Weight [kg] : 18448,00
