Brake Disc
78BD6572-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 17,7
Outer diameter [mm] : 238
Brake Disc Type : Vented
Height [mm] : 41
Centering Diameter [mm] : 61
Bolt Hole Circle [mm] : 100
Axle Version : Front
Technical Information Number : 78BD6572-2
Test Mark : E1 90R-02C0074/0411
Test Mark : E1 90R-02C0452/0079
Test Mark : E1190R02C01049/52490
Diameter [mm] : 61
Thickness [mm] : 20
Minimum thickness [mm] : 17,7
Hole Arrangement/Number : 4
Weight [kg] : 8060,000
