Brake Disc
78BD5640-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 8
Outer diameter [mm] : 253
Brake Disc Type : solid
Height [mm] : 51,2
Centering Diameter [mm] : 65
Bolt Hole Circle [mm] : 112
Axle Version : Rear
Technical Information Number : 78BD5640-2
Test Mark : E1 90R-02C0100/1208
Test Mark : E1 90R-02C0415/0089
Diameter [mm] : 65
Thickness [mm] : 10
Minimum thickness [mm] : 8
Hole Arrangement/Number : 9
Weight [kg] : 7284,000
