Brake Disc
78BD5619-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 10
Outer diameter [mm] : 282
Brake Disc Type : solid
Height [mm] : 48,3
Centering Diameter [mm] : 65
Bolt Hole Circle [mm] : 112
Axle Version : Rear
Technical Information Number : 78BD5619-2
Test Mark : E1 90R-02C0100/0676
Test Mark : E1 90R-02C0415/0088
Test Mark : E4 90R-02C0722/2585
Diameter [mm] : 65
Thickness [mm] : 12
Minimum thickness [mm] : 10
Hole Arrangement/Number : 9
Weight [kg] : 9564,000
