Brake Disc
78BD5615-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 22
Outer diameter [mm] : 288
Brake Disc Type : Vented
Height [mm] : 50
Centering Diameter [mm] : 65
Bolt Hole Circle [mm] : 112
Axle Version : Front & Rear
Technical Information Number : 78BD5615-2
Test Mark : E1 90R-02C0074/0979
Test Mark : E1 90R-02C0452/0083
Test Mark : E1190R02C01049/52502
Diameter [mm] : 65
Thickness [mm] : 25
Minimum thickness [mm] : 22
Hole Arrangement/Number : 5
Weight [kg] : 15064,00
