Brake Disc
78BD5606-1
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 8
Outer diameter [mm] : 245
Brake Disc Type : solid
Height [mm] : 84
Centering Diameter [mm] : 45
Bolt Hole Circle [mm] : 112
Axle Version : Rear
Technical Information Number : 78BD5606-1
Test Mark : E1 90R-02C0527/1458
Test Mark : E1 90R-02C0559/0102
Test Mark : E1190R02C01049/53741
Diameter [mm] : 45
Thickness [mm] : 10
Minimum thickness [mm] : 8
Hole Arrangement/Number : 5
Weight [kg] : 5740,000
