Brake Disc
78BD5563-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 17,4
Outer diameter [mm] : 294
Brake Disc Type : Vented
Height [mm] : 59
Centering Diameter [mm] : 75
Bolt Hole Circle [mm] : 120
Axle Version : Rear
Technical Information Number : 78BD5563-2
Test Mark : E1 90R-02C0506/1830
Test Mark : E1 90R-02C0587/0113
Diameter [mm] : 75
Thickness [mm] : 19
Minimum thickness [mm] : 17,4
Hole Arrangement/Number : 5
