Brake Disc
78BD5251-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 23
Outer diameter [mm] : 300
Brake Disc Type : Vented
Height [mm] : 47,1
Centering Diameter [mm] : 64,2
Bolt Hole Circle [mm] : 114,3
Axle Version : Front
Technical Information Number : 78BD5251-2
Test Mark : E1 90R-02C0074/0352
Test Mark : E1 90R-02C0452/0127
Test Mark : E4 90R-02C0703/2561
Diameter [mm] : 64,2
Thickness [mm] : 25
Minimum thickness [mm] : 23
Hole Arrangement/Number : 5
Weight [kg] : 16340,00
