Brake Disc
78BD5006-1
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 7
Outer diameter [mm] : 238
Brake Disc Type : solid
Height [mm] : 74,6
Centering Diameter [mm] : 52
Bolt Hole Circle [mm] : 100
Axle Version : Rear
Technical Information Number : 78BD5006-1
Test Mark : E1 90R-02C0527/1693
Diameter [mm] : 52
Thickness [mm] : 8
Minimum thickness [mm] : 7
Hole Arrangement/Number : 4
Weight [kg] : 4170,000
