Brake Disc
78BD4746-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 7,5
Outer diameter [mm] : 247
Brake Disc Type : solid
Height [mm] : 3,5
Centering Diameter [mm] : 71
Bolt Hole Circle [mm] : 108
Axle Version : Rear
Technical Information Number : 78BD4746-2
Test Mark : E1 90R-02C0100/0096
Test Mark : E1 90R-02C0415/0046
Test Mark : E1190R02C01049/43389
Diameter [mm] : 71
Thickness [mm] : 9
Minimum thickness [mm] : 7,5
Hole Arrangement/Number : 4
Weight [kg] : 6428,000
