Brake Disc
78BD4697-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 18,6
Outer diameter [mm] : 266
Brake Disc Type : Vented
Height [mm] : 27,5
Centering Diameter [mm] : 66
Bolt Hole Circle [mm] : 108
Axle Version : Front
Technical Information Number : 78BD4697-2
Test Mark : E1 90R-02C0289/1009
Test Mark : E1 90R-02C0433/0060
Test Mark : E1190R02C01049/43388
Diameter [mm] : 66
Thickness [mm] : 20,5
Minimum thickness [mm] : 18,6
Hole Arrangement/Number : 4
Weight [kg] : 9412,000
