Brake Disc
78BD4684-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 30
Outer diameter [mm] : 309
Brake Disc Type : Vented
Height [mm] : 43,7
Centering Diameter [mm] : 59
Bolt Hole Circle [mm] : 98
Axle Version : Front
Technical Information Number : 78BD4684-2
Test Mark : E1 90R-02C0339/1729
Diameter [mm] : 59
Thickness [mm] : 32
Minimum thickness [mm] : 30
Hole Arrangement/Number : 5
