Brake Disc
78BD4679-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 10
Outer diameter [mm] : 271,8
Brake Disc Type : solid
Height [mm] : 28,3
Centering Diameter [mm] : 59
Bolt Hole Circle [mm] : 98
Axle Version : Rear
Technical Information Number : 78BD4679-2
Test Mark : E1 90R-02C0100/0186
Test Mark : E1 90R-02C0415/0001
Diameter [mm] : 59
Thickness [mm] : 12
Minimum thickness [mm] : 10
Hole Arrangement/Number : 5
Weight [kg] : 8912,000
