Brake Disc
78BD3465-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 9,2
Outer diameter [mm] : 240
Brake Disc Type : solid
Height [mm] : 40
Centering Diameter [mm] : 59
Bolt Hole Circle [mm] : 98
Axle Version : Front & Rear
Technical Information Number : 78BD3465-2
Test Mark : E1 90R-02C0085/0006
Test Mark : E1 90R-02C0100/0893
Test Mark : E1 90R-02C0415/0028
Diameter [mm] : 59
Thickness [mm] : 11
Minimum thickness [mm] : 9,2
Hole Arrangement/Number : 4
Weight [kg] : 6980,000
