Brake Disc
78BD3392-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 11
Outer diameter [mm] : 256
Brake Disc Type : solid
Height [mm] : 39
Centering Diameter [mm] : 65
Bolt Hole Circle [mm] : 100
Axle Version : Front
Technical Information Number : 78BD3392-2
Test Mark : E1 90R-02C0100/0998
Test Mark : E1190R02C01049/52491
Diameter [mm] : 65
Thickness [mm] : 13
Minimum thickness [mm] : 11
Hole Arrangement/Number : 4
Weight [kg] : 8696,000
