Brake Disc
78BD3300-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 10
Outer diameter [mm] : 239
Brake Disc Type : solid
Height [mm] : 35,5
Centering Diameter [mm] : 65
Bolt Hole Circle [mm] : 100
Axle Version : Front
Technical Information Number : 78BD3300-2
Test Mark : E1 90R-02C0100/1163
Test Mark : E1 90R-02C0415/0038
Diameter [mm] : 65
Thickness [mm] : 12
Minimum thickness [mm] : 10
Hole Arrangement/Number : 4
Weight [kg] : 7048,000
