Brake Disc
78BD2593-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 29,4
Outer diameter [mm] : 330
Brake Disc Type : Vented
Height [mm] : 64,5
Centering Diameter [mm] : 67
Bolt Hole Circle [mm] : 112
Axle Version : Front
Technical Information Number : 78BD2593-2
Test Mark : E1 90R-02C0074/1445
Test Mark : E1190R02C01049/52398
Diameter [mm] : 67
Thickness [mm] : 32
Minimum thickness [mm] : 29,4
Hole Arrangement/Number : 5
