Brake Disc
78BD2093-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 26,4
Outer diameter [mm] : 316
Brake Disc Type : Vented
Height [mm] : 77
Centering Diameter [mm] : 79
Bolt Hole Circle [mm] : 120
Axle Version : Front
Technical Information Number : 78BD2093-2
Test Mark : E1 90R-02C0074/0089
Test Mark : E1 90R-02C0452/0085
Diameter [mm] : 79
Thickness [mm] : 28
Minimum thickness [mm] : 26,4
Hole Arrangement/Number : 5
Weight [kg] : 17776,00
