Brake Disc
78BD1213-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 10,3
Outer diameter [mm] : 290
Brake Disc Type : solid
Height [mm] : 53,5
Centering Diameter [mm] : 67
Bolt Hole Circle [mm] : 112
Axle Version : Rear
Technical Information Number : 78BD1213-2
Test Mark : E1 90R-02C0241/0208
Test Mark : E1 90R-02C0453/0106
Test Mark : E1190R02C 01049/5250
Diameter [mm] : 67
Thickness [mm] : 12
Minimum thickness [mm] : 10,3
Hole Arrangement/Number : 5
