Brake Disc
78BD1068-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 23
Outer diameter [mm] : 288
Brake Disc Type : Vented
Height [mm] : 46,2
Centering Diameter [mm] : 68
Bolt Hole Circle [mm] : 112
Axle Version : Front
Technical Information Number : 78BD1068-2
Diameter [mm] : 68
Thickness [mm] : 25
Minimum thickness [mm] : 23
Hole Arrangement/Number : 5
