Brake Disc
78BD0413-2
Catalog number:
Manufacturer:
ICER
Brake Disc Thickness [mm] : 8,3
Outer diameter [mm] : 300
Brake Disc Type : solid
Height [mm] : 68,5
Centering Diameter [mm] : 67
Bolt Hole Circle [mm] : 112
Axle Version : Rear
Technical Information Number : 78BD0413-2
Test Mark : E1 90R-02C0241/0033
Test Mark : E1 90R-02C0453/0099
Test Mark : E1190R02C01049/52387
Diameter [mm] : 67
Thickness [mm] : 10
Minimum thickness [mm] : 8,3
Hole Arrangement/Number : 5
